Place of Origin: | China |
Brand Name: | ECHO |
Certification: | ISO9001 |
Model Number: | Conveyor-38 |
Minimum Order Quantity: | 1 Sets |
---|---|
Price: | USD1000-USD5000 |
Packaging Details: | 1.Outside: wooden cartons 2. Inside: plastic bag. 3. According customer's require. |
Delivery Time: | 10-15 DAYS AGAINEST PI |
Payment Terms: | T/T 40% as deposit , balance before delivery |
Supply Ability: | 1000 SETS PER MONTH |
Condition: | New | Type: | Screw Conveyor |
---|---|---|---|
Material: | Carbon Steel | Material Feature: | Heat Resistant |
Structure: | Conveyor System | Load Capacity: | Strong |
Voltage: | 220/380V | Power(W): | 1.5KW |
Dimension(L*W*H): | Customized Size | Warranty: | 12 Months |
Usage: | Convey | Feature: | Simple Operation |
Motor: | China Standard Motor | Application: | Chemical/ Food / Industrial Etc. Industry |
Frame Material: | Stainless Steel/Carbon Steel | Capacity: | 10Kg-10Tons/hour |
After-sales Service Provided:: | No Overseas Service Provided |
Technical Parameters
ECHO Bucket elevator efficient features and purposes
1.ECHO-type bucket elevator with throughout, and enhance the high degree of high, stable, long life and so on. The application of dry bulk materials than vertical transmission, can be widely used in building materials, chemicals, coal, electricity, ports and transportation of material transport systems industry.
2.ECHO-style-type for the tape to EP and steel cord conveyor belt piece for traction. TH ring type chain to high-strength chain for traction case, the chain by GB/T12728-91"Mining high-intensity ring chain" manufacturing.
3.The tail of the plane of the first case were sealed and central processing, materials and dust rarely spill, causing very little environmental pollution.
4.The local mixed or gravity discharge, out check-type feed.
5.ECHO-type the last round for the assembled sprocket, flange bolts with high strength steel body is in rotation, the wear in the sprocket, just changing the rims, maintenance convenience, saving raw materials, reduce maintenance costs. Replaced by the next round flange, completely changed the original double-chain costs are high, easy to defect from the chain.
6.ECHO-type halo hypotenuse using the last round, the round has the role of self-centering, a conveyor belt to avoid deviation.
7.The models on the lower level and has a speed controller, the user can be made in accordance with the need to take in order to achieve the purpose of electric automatic control.
8.This machine up tight, there are two devices, for enhancing a high degree of not more than 25m high models, the general choice of screw up tight and a high degree of more than 25m upgrade the models, selection of gravity up tight, the special requirements of customers orders please indicate when.
Technical data:
Belt Width (mm) |
Belt Length(m) / Power(kw) |
Belt Speed (m/s) |
||
400 | ≤12/1.5 | 12-20/2.2 | 20-25/3 | 0.8-2 |
500 | ≤12/3 | 12-20/4 | 20-30/5.5 | 0.8-2 |
650 | ≤12/4 | 12-20/5.5 | 20-30/7.5 | 0.8-2 |
800 | ≤10/4 | 10-15/5.5 | 15-25/7.5 | 1.0-2 |
1000 | ≤10/5.5 | 10-20/7.5 | 20-25/11 | 1.0-2 |
1200 | ≤10/7.5 | 10-20/11 | 20-25/15 | 1.0-2 |
Note: The technical parameters above are just for your reference. If there is any change, all parameters and overall dimension are subject to operating instructions. Any questions please feel free to contact us.
Opearting principle:
Belt conveyor mainly composed by two endpoints drum and closed belt . Driven conveyor belt rotating drum called the drive roller ( rotate roller ) ; another change the direction of
movement of the conveyor belt rollers is called bend pulley only . The drive rollers by a motor through a speed reducer driven conveyor belt to rely on the friction drag between the drive
rollers and the conveyor belt . The drive rollers ships are mounted at the discharge end , to increase the traction, and is conducive to drag . Material from the feed end of the feeding ,
falls rotating conveyor belt , relying on the discharge end of conveyor belt friction driven transport bag unloading .
Production details
1 SET/ POLYWOOD CASE
We mainly export Vibrating machine, Lifting machine, mainly in
powder, starch, flour, rice flour, carbon powder, graphite powder, manganese powder, lithium carbonate Field.
1. We have very more experience in export business.
2. All of our products comply with international quality standards.
3.We can do customer’s design and requirement
4. We mainly export to Europe , Americal , South Americal, Africa, the Middle East. Australia, New Zealand etc.
