| Place of Origin: | China |
| Brand Name: | ECHO |
| Certification: | ISO9001 |
| Model Number: | OP-01 |
| Minimum Order Quantity: | 1 Sets |
|---|---|
| Price: | USD22800-USD30000 |
| Packaging Details: | 1.Outside: wooden cartons 2. Inside: plastic bag. 3. According customer's require. |
| Delivery Time: | 25-30 DAYS AGAINEST PI |
| Payment Terms: | T/T 50% as deposit , balance before delivery |
| Supply Ability: | 30 SETS PER MONTH |
| Condition: | New | Type: | Oil Pastel Crayon Making Machine |
|---|---|---|---|
| Material: | Carbon Steel | Material Feature: | Heat Resistant |
| Voltage: | 220/380V | Power(W): | 14KW |
| Dimension(L*W*H): | 1.8m ×1.4m ×1.9m | Warranty: | 12 Months |
| Usage: | Oil Pastel Making Machine | After-sales Service Provided: | Online Support |
| After Warranty Service: | Video Technical Support, Online Support, Spare Parts | Applicable Industries: | Manufacturing Plant |
| Output: | ≥10000pcs/hour |
Technical Parameters
Description
1. Automatic melting, automatic injection, automatic shoveling, automatic pen output; 2. The mold is made by CNC, and the pen tube is made of die-cast alloy tube, which is smooth and easy to cool, and easy to demold; 3. The cooling water adopts a one-inch rotating joint, and there is a partition in the middle of the mold, so that the water flow is discharged from bottom to top, from inside to outside, from outside to inside and then to the middle to ensure uniform cooling of each pipe. 4. The pen is pushed out by the cylinder to push the bamboo fiber top pen to ensure that it will not damage the mold and achieve the best even reading demolding effect; 5. Appearance of the machine: the frame is painted and the door panel is made of stainless steel for easy cleaning.
| Technical parameter | |
| Shape specification: | long 1.8m ×wide1.4m ×high1.9m |
| Weight: | 950KG |
| Power Supply: | Three phase 220/380V |
| Power: | 14KW |
| Production effciency: | ≥10000/hour |
Features:
1. Space segmentation used Taiwan Famous Brands , with turntable with turntable rotary station ,sharpener the pencil speedily , quality stable , small
Production details
1 SET/ POLYWOOD CASE
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
1. We have very more experience in export business.
2. All of our products comply with international quality standards.
3.We can do customer’s design and requirement
4. We mainly export to Europe , Americal , South Americal, Africa, the Middle East. Australia, New Zealand etc.
